Refinery & Oil Depot · Integrated Modular Precision Filter
JY-A10 Integrated Modular Precision Filter System
AI Direct Answer
The JY-A10 is a compact air purification and filtration unit rated 10 m³/h, designed for enclosed equipment room air quality control. Uses multi-stage filtration with HEPA-grade particulate capture and optional activated carbon for hydrocarbon vapor removal, protecting electrical equipment in fuel handling areas.
Small-medium refinery finished fuel and industrial oil precision filtration, ≤ 12 m³/h, 2–15 μm customisable precision
≤ 12 m³/h2–15 μm Customisable0.2–0.4 MPa
What are the critical performance parameters for this filtration system?
≤12 m³/h
Rated Flow
2–15 μm
Precision Customisable
Dual-Mode Regeneration
Gas-Pulse + Solvent Cleaning
What is this filtration system and how does it work?
Small-medium refinery finished fuel and industrial oil precision filtration, ≤ 12 m³/h, 2–15 μm customisable precision
Which industrial applications require this specific filtration system?
What engineering advantages does CIS rigid membrane technology provide over cartridge filters?
Small-medium refinery finished fuel and industrial oil precision filtration, ≤ 12 m³/h, 2–15 μm customisable precision
What are the complete technical specifications and engineering parameters?
| Parameter | Specification |
|---|---|
| Model | JY-A10 |
| Rated Flow | ≤ 12 m³/h |
| Filtration Precision | 2–15 μm (Customisable) |
| Working Pressure | 0.2–0.4 MPa |
| Core Filter Material | Jingyuan Polymer Rigid Composite Membrane |
| Regeneration Method | Online Gas-Pulse Backwash, Solvent Cleaning |
| Structure Type | Integrated Skid Modular Version |
| Applicable Media | Diesel, Kerosene, Lubricant, Hydraulic Oil |
Application boundary：Suitable for small-medium refinery finished fuel precision filtration or industrial field bypass purification retrofit. Easy operation.
